Rotary Drum Filter with UV Sterilizer & Bio-Filler
An all-in-one rotary drum filter system for aquaculture, combining mechanical filtration (75 μm), bio-filtration, and UV sterilization. Ideal for recirculating fish farming in fresh or seawater.
Rotary Drum Filter with UV Sterilizer & Bio-Filler
SKU: integrated-ras-system-rotary-drum-system-with-bio-filler-and-uv-sterilizer-fish-tank-water-filter
An all-in-one rotary drum filter system for aquaculture, combining mechanical filtration (75 μm), bio-filtration, and UV sterilization. Ideal for recirculating fish farming in fresh or seawater.
An all-in-one rotary drum filter system for aquaculture, combining mechanical filtration (75 μm), bio-filtration, and UV sterilization. Ideal for recirculating fish farming in fresh or seawater.
Specifications
| Place of Origin | Sichuan, China |
| Specification | NTRDS-10 |
| Manufacturer | NATIN |
| Instruction for use | reference operation manual |
| Brand Name | NATIN |
| Model Number | NTRDS-60 |
| Filter precision | 75 μm |
| Flow Rate | 10m³/h |
| UV Power | 40*2 |
| Air pump Power | 80W |
| Cleaning pump power | 1000W |
| Drum motor power | 15W |
| shell material | PP |
| Certificate | ISO9001 |
| Use range | freshwater seawater |
| Usage | Fish Farming Aquaclture |
| Selling Units | Single item |
| Single package size | 120X80X80 cm |
| Single gross weight | 60.000 KG |
Features & Benefits
- Three-stage filtration: mechanical drum filter (75 μm precision), integrated bio-filler, and dual 40W UV sterilizer for pathogen control.
- High flow rate of 10 m³/h (NTRDS-60 model) supports medium-scale aquaculture systems.
- Durable PP (polypropylene) shell resists corrosion in both freshwater and seawater environments.
- Energy-efficient components: 80W air pump, 1000W cleaning pump, and 15W drum motor for automated operation.
- ISO9001 certified quality from a trusted manufacturer (NATIN) with reference operation manual included.
Applications
- Recirculating Aquaculture Systems (RAS) for fish farms
- Freshwater and seawater aquariums and hatcheries
- Aquaponics systems requiring clear, biologically stable water
- Shrimp or other aquatic species cultivation
