Rotary Drum Filter - 200 Mesh, 5-10 m³/h
NATIN rotary drum filter for aquaculture and RAS systems. Customizable in PP/SS304/SS316L, 200-micron filtration, 5-10 m³/h flow rate.
Rotary Drum Filter - 200 Mesh, 5-10 m³/h
SKU: indoor-aquaculture-system-ras-system-customized-service-pp-material-koi-pond-drum-filter
NATIN rotary drum filter for aquaculture and RAS systems. Customizable in PP/SS304/SS316L, 200-micron filtration, 5-10 m³/h flow rate.
NATIN rotary drum filter for aquaculture and RAS systems. Customizable in PP/SS304/SS316L, 200-micron filtration, 5-10 m³/h flow rate.
Specifications
| Specification | Customized |
| Manufacturer | NATIN |
| Instruction for use | YES |
| Brand Name | NATIN |
| Model Number | NTR-5 |
| Product name | Rotary Drum Filter |
| Material | PP/SS304/SS316L |
| Flow rate | 5-10m³/h |
| Voltage | 220V/380V |
| Applicable water | Sea water, fresh water |
| Water intake | Pipe |
| OEM | Accept |
| Filtration Accuracy | 200 mesh |
| Power | 0.34kw |
| Weight | 35-260KG |
| Selling Units | Single item |
| Single package size | 105X105X90 cm |
| Single gross weight | 65.000 KG |
Features & Benefits
- Filtration accuracy of 200 mesh for fine solids removal
- Flow rate 5–10 m³/h suitable for small to medium systems
- Constructed from PP, SS304, or SS316L for corrosion resistance in fresh or saltwater
- Low power consumption at 0.34 kW with dual voltage 220V/380V options
- Fully customizable – size, material, and configuration available to match your system
Applications
- Indoor aquaculture and RAS systems
- Koi ponds and ornamental fish tanks
- Marine water (saltwater) filtration
- Recirculating aquaculture systems (RAS)
Features
Filtration accuracy of 200 mesh for fine solids removal
Flow rate 5–10 m³/h suitable for small to medium systems
Constructed from PP, SS304, or SS316L for corrosion resistance in fresh or saltw
Low power consumption at 0.34 kW with dual voltage 220V/380V options
Fully customizable – size, material, and configuration available to match your s
